This receiver is NOT made by Spektrum. Spektrum, DSM2, DSMX are registered trademarks of Horizon Hobby.

Features:

• Enclosed in heat-shrink wrapping and very light weight.
• Support PPM, good for FPV racing drone use.

Binding Instructions:

Make sure the transmitter is powered off. Power on the DSM2/DSMX receiver. Long press the gold pair button. After around 2 seconds the LED changes to fast flashing. Now the receiver is in pairing mode. Then turn on the transmitter and change the transmitter to pairing mode. Wait for the receiver LED to change from fast flashing to off. Now the pairing is complete. Power off the transmitter and receiver then power on again then the receiver should work.

Specifications:

• Frequency: 2.4GHz
• Channel: 9CH
• Mode: DSM-X (Backward compatible with DSM2)
• Input Voltage: 3.5-9.6V
• Weight: 2g
• Dimensions: 22 x 15mm
