Items Needed to Complete

Specifications:

• Wingspan: 59 in (1500 mm)
• Length: 39.6 in (1005 mm)
• Wing Area: 418.5 sq in (27 sq dm)
• Flying Weight: 2.9 lb (1300 g)
• Motor: BM3720A-KV650 Brushless Outrunner
• Speed Controller: 40A ESC
• Servo: 6 x 9g

Still Required:

• 2200mAh 4s 14.8V LiPO
• Your Own Transmitter and Receiver.

More discussion about this plane on RC Groups

This information is provided by our customer, Norman Coates

I found another major problem that I fortunately discovered before the madden flight. A very important piece of information on the assembly sheet is very wrong! The location of the C.G. The drawing on the instruction sheet clearly shows the C.G. being measured from the leading edge of the wing, not the wing root, and the measurement to be 95-100 mm. This location would make the model extremely tail heavy and would cause disastrous results on the first flight. From my experience I figured the C.G. to be approximately 65mm from the leading edge and it worked perfectly. The model flies very well balanced with the C.G. at this location.
