Features:

• Built-in a three-axis gyro and three-axis acceleromter sensor module
• Built-in RSSI PWM ourput (0~3.3V) on board
• Built-in battery voltage sensor
• Smart Port enabled

Specifications:

• Compatibility: FrSky Taranis X9D Plus/X9E/Horus X12S/XJT in D16 mode, S6R-EU only works with Horus X12S and Taranis X9D Plus/X9E-EU/XJT-EU in D16-EU mode.
• Dimension: 47.42*23.84*14.7mm(L*W*H)
• Weight: 12.1g
• Operating Range: full range
• Operating Voltage Range: 4.0~10V
• Operating Current: 100mA@5V
• Number of Channels: 6CH（1~6CH from conventional channel outputs）
• Measurement Range: ±4g
