Features:

• Safety arming feature: Regardless the throttle stick position, the motor will not spin after battery connected.
• Throttle calibration function: Throttle range can be calibrated to be compatible with different transmitters.
• User programmable.
• Multiple program methods supported: transmitter stick, LED Program Card. Very easy to program the ESC at home or at the flying field.
• Compatible with LiPO and NiMH battery.
• Timing can be changed to be suitable for different brushless motors.
• Full protection: Low voltage cutoff protection / Over-heat protection / Throttle signal loss protection.
• Power connectors and motor connectors are not included.

Specification

• Output: Continuous 60A, Burst 80A up to 10 seconds.
• Input Voltage: 2-6S Lipo, 5-18 cells NiMH.
• BEC: 5A / 5V Switch Mode BEC.
• Refresh rate of the throttle signal: 50Hz to 432Hz.
• Max Speed: 210000rpm for 2 Poles BLM, 70000rpm for 6 poles BLM, 35000rpm for 12 poles BLM. (BLM = Brushless Motor)
• Connectors: 4mm bullet connectors and T-Connector pre-soldered.
• Dimensions: 3 * 1.4 * 0.6in.
• Weight: 2.3oz
