Feature:

• The STM32F405 MCU which features the powerful computing capability and super-high running frequency allows the FC to run the PID and gyro with higher frequency.
• Besides the latest Dshot 150/300/600/1200 mode, the FC also supports the regular PWM mode, Oneshot125 mode, Oneshot42 mode and Multishot mode.
• A TF-card can be inserted into the FC to record and save more flight data,  which allows users to adjust their aircraft easily.
• Onboard OSD microchip allows users to easily adjust various (OSD) parameters via the Betaflight/Cleanflight software.
• The FC which supports Betaflight/Cleanflight firmware & allows parameter adjustment via Betaflight /Cleanflight software is more applicable to FPV flying & racing.
• It’s easy to wire and install when pairing the FC with a Hobbywing 4-in-1 tower ESC & a HOBBYWING VTX (Video Transmitter).

Specifications:

• Compatible with (Multirotors): Quadcopters, hexacopters
• Firmware: OMNIBUSF4SD
• FC Programming: Supported
• Programming Via: Betaflight/Cleanflight-configurator
• Compatible with (Modes): PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
• Compatible with (Transmitters): PPM, Spektrum, SBUS, SUMD, SUMH, XBUS, IBUS, JETIEXBUS, CRSF, SRXL
• OSD: Built-in
• Voltage Monitoring: Supported
• Current Monitoring: Supported
• External Buzzer: Supported
• LED Control: Supported
• TF-card: Supported (Maximum: 32g)
• USB Port: MicroUSB
• Dimension: 1.4 x 1.4in / 35 x 35mm
• Weight: 0.2oz/6g
