Details
Features:
- High Torque
- High Speed
- Standard Size Servo
- Dual Ball Bearing
- Coreless Motor
- Titanium Shielded 7075 Alloy Gear Train
Specifications:
- Torque(6.0V): 14.0 kg-cm (194.42 oz/in)
- Torque(7.4V): 16.0 kg-cm (222.20 oz/in)
- Speed: 0.14 sec (6.0V) │ 0.12 sec (7.4V)
- Operating Voltage: 6.0 ~ 7.4 DC Volts
- Weight: 64.0 g (2.26 oz)
- Bearing Type: Ball Bearing x 2
- Motor Type: Coreless Motor
- Gear Type: Titanium Shielded 7075 Alu
- Working frequence: 1520μs / 333hz
- Dimension: 40.3x 20.2 x 37.2 mm ( 1.58 x 0.80 x 1.46 in)
Additional Information
| SKU | PHD-SV-3039 |
|---|---|
| Size/Class | Standard |
| Digital/Analog | Digital |
| Gear Type | Metal |
| Torque (oz/in) | 222.20 |
| Speed (sec/60 deg) | 0.12 |
| Weight (gram) | 64 |
| Brand | Power HD |
Customer Reviews
- Great Servos Review by dbrc
-
I purchased these servos for my new Ventique 60" electric airplane and they work great. Servos are very fast, strong and center perfectly. I highly recommend them for 60-90 size airplanes. Have had great results with all the Power HD servos I have purchased. BTW I use them with a life battery, not necessary to use 7.4 volt lipo. (Posted on 5/25/2015)Quality Value Overall
