Features:

• 1.Current level is adjustable, Meet your variety of application requirements
• 2. Current is automatic adjustable
• 3. 6N137 high-speed optical coupling, guarantee high speed without losing step.
• 4. Employing thick radiator, Good heat dissipation

Specifications:

• 1. Working voltage DC 10V-35V.you are adviced to use DC 24V
• 2. It use high speed light lotus root to sure high speed with no step out
• 3. There is low pressure off,stop when overheating or strong current
• 4. The rated maximum output: ±3A，Vpp 3.5A.
• 5. Suit for two-phase/four-phase/six-phase,stepping motor under 3A current,but not suit for stepping motor higher than 3A.
• 6. Half a stream automatically
• 7. Subdivide: synchronizing, half step,1/8 step,1/16 step,16 divide at most
• 8. Size:50*75*35
