Details
Specification:
- KV: 1200
- Stator Diameter: 22mm
- Stator Length: 16mm
- Shaft Diameter: 3mm
- Motor Dimension: Φ27.5×34mm
- Weight(g): 64g/2.26oz
- No.of Cells(Lipo): 2-3S
- Max Continuous current(180S): 23A
- Max Continuous Power(180S): 245W
- Internal resistance: 48mΩ
- Configuration: 12N14P
- Motor connectors NOT installed
Recommended Setup:
- 30A brushless motor ESC
- 3S LiPO and at least 1100-2000mAh.
- Prop Selection: Remember to always use props designed for electric motors, nitro props are heavier and might overload the motor.
With 3S LiPO: 10x4.7, 9x4.7 - The above prop selections are recommended for sports flying at open throttle. You may try using larger props if you do not fly at constant open throttle.
Additional Information
| SKU | VHB-MT-1376 |
|---|---|
| Motor Weight (g) | 64 |
| KV | 1200 |
| Estimated Output (watt) | 200 |
| Motor Type | Out-Runner |
| Motor Class | Park-400 |
| Motor Usage | Airplane |
Customer Reviews
- It's a runner... Review by DS_Meerkat
-
I purchased this motor for my 35in Cap Profile Plane, coupled with a 1047SF prop this motor purred. I pulled hard and never had one issue with it working as hard as it could. I will definitely be buying more motors of this type. My only word of advice on this motor is, buy an extras shaft or two, they bend kinda easily. (Posted on 4/10/2013)Quality Value Overall
