1 Specification
1.1 Output: Continuous current 35A, burst current 190A.
1.2 Input: 4-9 cells NiMH/NiCd or 2-3 cells LiPo.
1.3 BEC Output: 6V/1.5A.
1.4 Resistance: 0.0015 Ohm.
1.5 Motor Supported: Sensorless Brushless Motor
1.6 Suitable Brushless Motor:

With 4-6 cells NiMH/NiCd or 2 cells Lipo: On-Road≥9T, Off-Road≥12T;
With 6-9 cells NiMH/NiCd or 3 cells Lipo: On-Road≥12T, Off-Road≥18T;

1.7 Suitable Car: 1/12, 1/10 on-road or off-road cars / trucks for normal race or sportful race.
1.8 Size: 31.5mm(L) * 27.5mm(W) * 24mm(H).
1.9 Weight: 30g(Without wires)

2 Features
2.1 Compatible with all sonsorless brushless motor.
2.2 Use top quality electronic components to enhance the current endurance ability of the ESC.
2.3 Excellent start-up, acceleration and linearity features.
2.4 With 3 running modes: Racing mode (Forward), Forward/Backward mode and Rock Crawler mode.
2.5 With 4 steps of maximum reverse force adjustment.
2.6 Proportional ABS brake function with 4 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment.
2.7 With 9 start modes (Also called "Punch" ) from "Soft" to "Very aggressive" to suitable for different tracks.
2.8 Multiple protection features: Low voltage cut-off protection for lithium or nickel battery / Over-heat protection / Throttle signal loss protection / Motor blocked protection.
2.9 With 8 steps of timing adjustment to get the best compatibility with various of motors.
2.10 Easily program with only one button and compatible with pocket-sized program card.
2.11 The ESC is USB supported. The firmware of the ESC can be updated through an USB adapter on the Advanced LCD Program Box (Optional device).

3 Programmable Items (Click the following picture to enlarge it)
