Details
1 Specification
1.1 Output: Continuous current 60A, burst current 380A.
1.2 Input: 4-9 cells NiMH/NiCd or 2-3 cells LiPo.
1.3 BEC Output: 6V/1.5A.
1.4 Resistance: 0.0007 Ohm.
1.5 Motor Supported: Sensorless Brushless Motor
1.6 Suitable Brushless Motor:
With 4-6 cells NiMH/NiCd or 2 cells Lipo: On-Road≥5.5T, Off-Road≥8.5T;
With 6-9 cells NiMH/NiCd or 3 cells Lipo: On-Road≥8.5T, Off-Road≥13T;
1.7 Suitable Car: 1/12, 1/10 on-road or off-road cars / trucks for normal race or sportful race.
1.8 Size: 31.5mm(L) * 27.5mm(W) * 24mm(H).
1.9 Weight: 32g(Without wires)
2 Features
2.1 Compatible with all sonsorless brushless motor.
2.2 Use top quality electronic components to enhance the current endurance ability of the ESC.
2.3 Excellent start-up, acceleration and linearity features.
2.4 With 3 running modes: Racing mode (Forward), Forward/Backward mode and Rock Crawler mode.
2.5 With 4 steps of maximum reverse force adjustment.
2.6 Proportional ABS brake function with 4 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment.
2.7 With 9 start modes (Also called "Punch" ) from "Soft" to "Very aggressive" to suitable for different tracks.
2.8 Multiple protection features: Low voltage cut-off protection for lithium or nickel battery / Over-heat protection / Throttle signal loss protection / Motor blocked protection.
2.9 With 8 steps of timing adjustment to get the best compatibility with various of motors.
2.10 Easily program with only one button and compatible with pocket-sized program card.
2.11 The ESC is USB supported. The firmware of the ESC can be updated through an USB adapter on the Advanced LCD Program Box (Optional device).
3 Programmable Items (Click the following picture to enlarge it)
Additional Information
| SKU | HWG-SC-0248 |
|---|---|
| Output | 60 |
| Input Voltage | 2-4S LiPO |
| Usage | Car |
| BEC | Built-in Linear BEC |
| ESC Series | Hobbywing eZRun |
Customer Reviews
- great esc Review by jay
-
you will not be disapointed . (Posted on 1/15/2013)Quality Value Overall - Not recommended Review by TJ
-
The build quality of this unit is nice, the programming is easy to learn and work with, and I like the price tag. Bad news is it has an issue with full throttle. Pull the trigger once and it works great, green light on ESC comes on indicating you're at 100% throttle. Let go of the trigger and quickly pull it again, and the ESC will not go back to full throttle, it limits itself to what I would estimate to be about 75% of full throttle. It's an absolute nightmare trying to drive this on the track, because half the time when you need that full throttle punch, it's not there.Quality Value Overall
I've emailed Hobbywing support twice and they have been worthless in helping me with the problem. I found a youtube video of another owner having the EXACT same problem, I linked Hobbywing the video but they are based in China and cannot view it. I've only driven with this ESC maybe 3 times and I'm replacing it already. You get what you pay for.... (Posted on 9/26/2012)
