Details
Specification
1.1 Output: Continuous current 70A, burst current 520A;
1.2 Input: 6-9 cells NiMH/NiCd or 2-3S Lipo;
1.3 BEC Output: 6V/3A (Linear mode);
1.4 Resistance: 0.0007 Ohm;
1.5 Motor Supported: Sensorless Brushless Motor
1.6 Suitable Brushless Motor:
With 6 cells NiMH/NiCd or 2S Lipo: KV≤6000;
With 7-9 cells NiMH/NiCd or 3S Lipo: KV≤4000;
1.7 Suitable Car: 1/10th scale 2WD short course truck / buggy / monster;
1.8 Size: 53.5mm(L) * 36mm(W) * 36mm(H).
1.9 Weight: 88g;
Features
2.1 Integrated and compact design, very suitable for short course trucks and buggies.
2.2 The built-in switching mode BEC of EZRUN-SC8 ESC has a powerful output to supply all electronic equipments even with 4S Lipo input.
2.3 Excellent start-up, acceleration and linearity features.
2.4 With 3 running modes: Racing mode (Forward), Forward/Backward mode and Rock Crawler mode.
2.5 With 4 steps of maximum reverse force adjustment.
2.6 Proportional ABS brake function with 5 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment.
2.7 Compatible with mechanical disc-brake system.
2.8 With 9 start modes (Also called "Punch" ) from "Soft" to "Very aggressive" to suitable for different tracks.
2.9 Multiple protection features: Low voltage cut-off protection for lithium or nickel battery / Over-heat protection / Throttle signal loss protection / Motor blocked protection.
2.10 With 8 steps of timing adjustment to get the best compatibility with various of motors.
2.11 Easily program with only one button and compatible with pocket-sized LED Program Card and the Advanced LCD Program Box.
2.12 ESC firmware updatable via an USB adapter on the Advanced LCD Program Box.
2.13 The major electronic components are sealed against splashing water and dust.
2.14 2 mounting holes on the bottom are helpful for firmly installing the ESC on the chassis.
Additional Information
| SKU | HWG-SC-0897 |
|---|---|
| Output | 70 |
| Input Voltage | 2-4S LiPO |
| Usage | Car |
| BEC | Built-in Linear BEC |
| ESC Series | Hobbywing eZRun |
Customer Reviews
- awesome products.and u guys always r in stock Review by Gabriel
-
this esc is awesome because 1.you can program it.2.it has a fan that is built into esc and does not take up space in the receiver area.3.not one of my esc have burned up,such as castle creations,lrp and vxl yes traxxas products,mambamonster.i use the hobbywing 150 amp .and I have 2emaxxs and 2 erevos (Posted on 11/25/2014)Value Overall Quality - Another excellent Hobbywing ESC. Thank you Value Hobby Review by Michael
-
Fit perfectly in my new traxxas LCG 2wd chassis. Does what it is supposed to do and the value is off the chart (Posted on 5/17/2014)Overall Quality Value - 55 $$$ Review by ross
-
Very well made and stays cool, I have two of them one in a Slash and one in a HPI touring car. Ok Slash first, it loves to be wide open on a lower punch control but change it to level 7 and hold on. Make sure to glue your tires very well or it will rip them off and I just use a Tacon 3930kv 2pole motor and a 3cell 60c battery, will try level 9 punch control with a 4pole motor next. As for the car I use a Traxxas Velineon motor. The punch control works very well on a track keeps you from spinning out. On the road I let it rip with a 3cell 40c battery and its everything you need and more, for 55 dollars you would think ok I'm getting what I paid for but you're not you're getting more for your money than high dollar brands. (Posted on 5/4/2013)Quality Value Overall - Amazing Review by Dan
-
Just simply amazing. Ran packs empty in 100 degree heat esc never went over 85! The motor on the other hand smoked lol go Hobbywing! (Posted on 4/17/2013)Value Overall Quality - Top notch Review by Chris
-
Would not buy anything else, have both the 70 amp and 120 amp . Sure beats the other high priced stuff out there , lots of settings and so easy to program. (Posted on 10/23/2012)Value Overall Quality - This ESC runs very cool Review by Bradley
-
I love this ESC. It was very decently priced and it runs very cool. I love it and I would definitly buy another. (Posted on 9/13/2012)Overall Quality Value - Awesome ESC Review by Gregory
-
This ESC is prolly one of the best ESCs on the market. It simply blows away any of the castle products in features, durability, performance, and value. Nothing but good things to say about this Hobbywing ESC. (Posted on 9/7/2012)Quality Value Overall
