Details
Specification
1.1 Output: Continuous current 120A, burst 760A up to 10 Secs.
1.2 Input: 6-12 cells NiMH/NiCd or 2-4S Lipo;
1.3 BEC Output: 6V/3A (Switching mode);
1.4 Resistance: 0.0004 Ohm;
1.5 Motor Supported: Sensorless Brushless Motor
1.6 Suitable Brushless Motor:
With 6 cells NiMH/NiCd or 2S Lipo: KV≤6000;
With 7-9 cells NiMH/NiCd or 3S Lipo: KV≤4000;
With 10-12 cells NiMH/NiCd or 4S Lipo: KV≤3000;
1.7 Suitable Car: 1/8th scale 4WD short course truck (Include TRAXXAS 1/10th scale short course truck) / buggy ;
1.8 Size: 53.5mm(L) * 36mm(W) * 36mm(H).
1.9 Weight: 98g;
Features
2.1 Integrated and compact design, very suitable for short course trucks and buggies.
2.2 The built-in switching mode BEC of EZRUN-SC8 ESC has a powerful output to supply all electronic equipments even with 4S Lipo input.
2.3 Excellent start-up, acceleration and linearity features.
2.4 With 3 running modes: Racing mode (Forward), Forward/Backward mode and Rock Crawler mode.
2.5 With 4 steps of maximum reverse force adjustment.
2.6 Proportional ABS brake function with 5 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment.
2.7 Compatible with mechanical disc-brake system.
2.8 With 9 start modes (Also called "Punch" ) from "Soft" to "Very aggressive" to suitable for different tracks.
2.9 Multiple protection features: Low voltage cut-off protection for lithium or nickel battery / Over-heat protection / Throttle signal loss protection / Motor blocked protection.
2.10 With 8 steps of timing adjustment to get the best compatibility with various of motors.
2.11 Easily program with only one button and compatible with pocket-sized LED Program Card and the Advanced LCD Program Box.
2.12 ESC firmware updatable via an USB adapter on the Advanced LCD Program Box.
2.13 The major electronic components are sealed against splashing water and dust.
2.14 2 mounting holes on the bottom are helpful for firmly installing the ESC on the chassis.
Additional Information
SKU | HWG-SC-0898 |
---|---|
Output | 120 |
Input Voltage | 2-4S LiPO |
Usage | Car |
BEC | Built-in Switching BEC |
ESC Series | Hobbywing eZRun |
Customer Reviews
- Buy one you will like it. Review by Michael
-
Quality Value Overall - This bad boy rocks on my 1/8 RC10 8.2e RS RTR 4WD buggy! Review by Bubaa
-
Quality Value Overall
Got this bad boy installed. Previously ordered the 150A esc but unfortunately doesn't fit the buggy. Gargantuan!!.. Exchange for this one instead which is nice and small. Boy oh boy! With my Genace 4S. 30C....hold on tight! My 8.2e has suddenly come back to life with more boost!....So !@#$%!! fast!!! No more cogging! Yaa.....
Thanks VH for an awesome product. (Posted on 6/27/2013) - great power Review by khalid
-
Quality Value Overall - amazed Review by Blake
-
Quality Value Overall - great esc at a great price Review by wayne
-
Quality Value Overall
